Product Introduction
1. This CO2 laser engraver cutting machine is ideal for consumer use or small scale start up businesses, this versatile and high performance Laser Engraver will soon become an integral part of your company.
2. With it’s premium design features and an abundance of power, this machine is an excellent fit for a whole range of applications.
3. ZGD-4060 B laser engraving machine high strength, high stable mechanical structure design, CNC running smoothly.
4. With unique deceleration setting, the machine performance is more stable and the finished product line is smooth.
5. The edges of the engraving sample are smooth and smooth; The function of a break – point memory continues to be processed outside or in the next day.
6. Machine structure: The upgraded version is reinforced on the machine structure and is more stable, and the shape is more beautiful.
Production process: The updated version is more detailed in the production process, has the independent water temperature test table, the power box thermometer, the accuracy of the work is higher.
7. Widely used for advertising industry, bamboo wood crafts industry, wood packaging industry, decoration industry, furniture industry, model production and other industries.
8. This machine has 1 Year Return to Base Warranty!
Important Note
1. CHECK THE VIDEO ON THE CD BEFORE USING THIS MACHINE!
2. With regards to our Laser Engravers, please note that the 40 watt machines are only for engraving purposes; 50 watt versions can be used for both engraving and cutting; 60 watt would complete the applications quicker and more efficiently.
3. Please note that it is necessary to use a water cooling system before powering on and use to maintain and protect the laser tube. Any overheating to the laser tube shall and will cause damage to the internal mirrors. Any damaged that is caused due to overheating will not be replaced. Please ensure to correctly use the water cooling system to cool the laser after every use.
4. For cutting purpose please make sure it’s under low percentage power, low speed and not for a long time cutting, incorrect using will much lower the life using of the laser tube, can easily use up the laser tube.
Specifications
Product name: CO2 Laser Engraver Cutting Machine
Model: ZGD-4060
Guide: Inner slide guide rail
Laser head: New adjustable laser head
Feed: In frond of the feed
Display panel: Ordinary panel
Color: Blue and White
Lift: Yes
Blow: Yes
Red light positioning: Yes
Laser type: CO2 sealed off glass tube laser
Power supply voltage: AC 220 ± 10%/ AC 110 ± 10% 50 Hz/ 60 Hz
Power: 60 W
Effective ared: 600 x 400 mm
Engraving speed: 1 to 700mm/s
Control configuration: DSP
Date transmission interface: USB
System environment: WINDOW 2000/ WINDOWS xp
Cooling way: water cooled
Water break protection: Yes
Packaging: Plywood wooden cases
Dimensions: 138*74*58 cm
Weight: 55 Kg
Packaging Content
Water Pump x 1
Smoke Pipe x 1
Main Body x 1
Air Pump x 1
Power Line x 1
Wrench x 1
Usb key x 1
Laser Tube x 1
CD x 1
Manual x 1
USB Cable x 1
Manual/Accessory Bag x 1
